Secure Cellular/Satellite Telephone Encryption Device

Model: AA77113

No Image Available

The AA77113 is a compact, portable, easy-to-use, high-grade encryption system which ensures that your voice communication is secure. When connected to satellite user terminals, data capable digital cellular telephones or satellite telephone handsets the AA77113 provides high-grade secure voice encryption, decipherable only by another phone using the same device and encryption key (note-two devices are required for two-way encrypted communication). This device is also compatible with the AA77114 (DCS-1200) allowing encrypted landline to satellite/cellular phone conversations. The AA77113 can be used with model AA77140 (data dock required) and model AA77141 (additional cables required). Please specify which satellite or cellular system you will be using so we can provide you with the correct model.

When connected to satellite user terminals, data capable digital cellular telephones or satellite telephone handsets the AA77113 provides high-grade secure voice encryption. In this day and age, government, business and personal communications need to be kept confidential, and encrypted information can not be decrypted and read by an unauthorized person. The AA77113 utilizes either the ultimate digital encryption algorithm of the day - the CitadelTM CCX, the new Advanced Encryption Standard (AES) or the Triple DES digital cryptographic algorithm.

This product is approved by the U.S. Department of Commerce for export without a license to all countries except, Syria, Libya, Sudan, Iran, Iraq, Cuba, and North Korea. All encryption equipment is considered a custom order and as such is not returnable.

  • Encryption Algorithm:Harris CITADELTM CCX, Triple DES or the Advanced Encryption Standard (AES): one algorithm per unit
  • Cryptographic Traffic Encryption Key:Minimum 3.4 x 1038 combinations (128-bit key length)
  • Minimum Communication Speed:2400 bps throughput
  • Cellular/Satellite Phone Connector: DB-9
  • Weight:3 oz (85 g)
  • Power Source:90 to 240 V AC 50 to 60 Hz
  • Battery:>Lithium Ion, providing up to 6 hours of secure operation in the wireless mode. Secure operation is possible while charging
  • Power Consumption: 0.6 Watts
  • Dimensions:5" x 2.2" x 0.4" (127 x 56 x 10 mm)
